FRONT WHEEL
0
BLV1
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | BLVF51680033 | CAST WHEEL, FRONT | ₹ 7065 | 1 | ||
| 1B | BLVF516800P1 | CAST WHEEL, FRONT | ₹ 7065 | 1 | ||
| 1C | BLVF516800P2 | CAST WHEEL, FRONT | ₹ 7065 | 1 | ||
| 1D | BLVF5168008L | CAST WHEEL, FRONT | ₹ 7065 | 1 | ||
| 2 | 903871084800 | COLLAR | ₹ 102 | 1 | ||
| 3 | 931062081600 | OIL SEAL | ₹ 25 | 2 | ||
| 4 | 93306300YN00 | BEARING | ₹ 124 | 2 | ||
| 5 | B9EF517G0000 | ROTOR SENSOR | ₹ 107 | 1 | ||
| 6 | 901490503000 | SCREW | ₹ 21 | 3 | ||
| 7 | 941111481400 | TIRE | ₹ 0 | 1 | ||
| 8 | 939000082400 | VALVE RIM | ₹ 19 | 1 | ||
| 9 | 903871027700 | COLLAR | ₹ 25 | 2 | ||
| 10 | BEPF51810000 | AXLE WHEEL | ₹ 96 | 1 | ||
| 11 | 956021020000 | NUT U FLANGE | ₹ 32 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA BLV1 AEROX Series FRONT WHEEL
