SIDE COVER
0
BLV8
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BEPF17110000 | COVER SIDE 1 | ₹ 164 | 1 | ||
| 2 | 901600581400 | SCREW ROUND TAPPING | ₹ 5 | 2 | ||
| 3 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 4 | BEPF17210000 | COVER SIDE 2 | ₹ 164 | 1 | ||
| 5 | 901600581400 | SCREW ROUND TAPPING | ₹ 5 | 2 | ||
| 6 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 7A | BEPXF17300P4 | BEPXF17300P4 | ₹ 0 | 1 | FOR DPBMY | |
| 7B | BEPXF17350P3 | BEPXF17350P3 | ₹ 0 | 1 | FOR MLNM4 | |
| 8A | BLVF173E7000 | BLVF173E7000 | ₹ 0 | 1 | FOR DPBMY | |
| 8B | BLVF173E5000 | BLVF173E5000 | ₹ 0 | 1 | FOR MLNM4 | |
| 9 | BLVF173X1000 | BLVF173X1000 | ₹ 0 | 1 | FOR DPBMY | |
| 10 | BLVF17881000 | BLVF17881000 | ₹ 0 | 1 | FOR DPBMY | |
| 11 | 901600581400 | SCREW ROUND TAPPING | ₹ 5 | 2 | ||
| 12 | 901830580700 | NUT SPRING | ₹ 9 | 3 | ||
| 13 | 905201085300 | SEAT PIPE | ₹ 20 | 1 | ||
| 14A | BEPXF17400P4 | BEPXF17400P4 | ₹ 0 | 1 | FOR DPBMY | |
| 14B | BEPXF17450P3 | BEPXF17450P3 | ₹ 0 | 1 | FOR MLNM4 | |
| 15A | BLVF173F7000 | BLVF173F7000 | ₹ 0 | 1 | FOR DPBMY | |
| 15B | BLVF173F5000 | BLVF173F5000 | ₹ 0 | 1 | FOR MLNM4 | |
| 16 | BLVF173Y1000 | BLVF173Y1000 | ₹ 0 | 1 | FOR DPBMY | |
| 17 | BLVF17881000 | BLVF17881000 | ₹ 0 | 1 | FOR DPBMY | |
| 18 | 901600581400 | SCREW ROUND TAPPING | ₹ 5 | 2 | ||
| 19 | 901830580700 | NUT SPRING | ₹ 9 | 3 | ||
| 20 | 905201582200 | SEAT PIPE | ₹ 60 | 1 | ||
| 21 | BEPF171N0000 | MOLE SIDE COVER 3 | ₹ 87 | 1 | ||
| 22 | 977025001200 | SCREW TAPPING | ₹ 11 | 2 | ||
| 23 | 901600581400 | SCREW ROUND TAPPING | ₹ 5 | 1 | ||
| 24 | 902690681600 | RIVET | ₹ 14 | 1 | ||
| 25 | BEPF171R0000 | MOLE SIDE COVER 4 | ₹ 84 | 1 | ||
| 26 | 977025001200 | SCREW TAPPING | ₹ 11 | 2 | ||
| 27 | 901600581400 | SCREW ROUND TAPPING | ₹ 5 | 1 | ||
| 28 | 902690681600 | RIVET | ₹ 14 | 1 | ||
| 29A | BEPXF17C10P1 | BEPXF17C10P1 | ₹ 0 | 1 | FOR DPBMY | |
| 29B | BEPXF17C00P5 | BEPXF17C00P5 | ₹ 0 | 1 | FOR MLNM4 | |
| 30A | BLVF174G5000 | BLVF174G5000 | ₹ 0 | 1 | FOR DPBMY | |
| 30B | BLVF174G3000 | BLVF174G3000 | ₹ 0 | 1 | FOR MLNM4 | |
| 31A | BLVF174J5000 | BLVF174J5000 | ₹ 0 | 1 | FOR DPBMY | |
| 31B | BLVF174J3000 | BLVF174J3000 | ₹ 0 | 1 | FOR MLNM4 | |
| 32A | BEPXF17N10P1 | BEPXF17N10P1 | ₹ 0 | 1 | FOR DPBMY | |
| 32B | BEPXF17N00P5 | BEPXF17N00P5 | ₹ 0 | 1 | FOR MLNM4 | |
| 33A | BLVF174H5000 | BLVF174H5000 | ₹ 0 | 1 | FOR DPBMY | |
| 33B | BLVF174H3000 | BLVF174H3000 | ₹ 0 | 1 | FOR MLNM4 | |
| 34A | BLVF174K5000 | BLVF174K5000 | ₹ 0 | 1 | FOR DPBMY | |
| 34B | BLVF174K3000 | BLVF174K3000 | ₹ 0 | 1 | FOR MLNM4 | |
| 35 | BEPF171T0000 | MOLE SIDE COVER 5 | ₹ 111 | 1 | ||
| 36 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 4 | ||
| 37 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 38 | 902690681200 | RIVET | ₹ 20 | 4 | ||
| 39A | BEPXF47100P1 | COVER TAIL 1 LH | ₹ 140 | 1 | FOR DPBMY | |
| 39B | BEPXF47100P5 | BEPXF47100P5 | ₹ 0 | 1 | FOR MLNM4 | |
| 40 | BEPF836B0000 | TUNING FORK MARK | ₹ 30 | 1 | ||
| 41 | 901600581400 | SCREW ROUND TAPPING | ₹ 5 | 1 | ||
| 42 | BEPF472K0000 | COVER TAIL 2 | ₹ 129 | 1 | ||
| 43 | 905201085000 | SEAT PIPE | ₹ 20 | 2 | ||
| 44 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 4 | ||
| 45 | 901090622000 | BOLT | ₹ 19 | 1 | ||
| 46 | BEPF18710000 | TANK RECOVERY | ₹ 277 | 1 | ||
| 47 | 905200282900 | DAMPER PLATE | ₹ 18 | 1 | ||
| 48 | 901090622000 | BOLT | ₹ 19 | 1 | ||
| 49 | 904801480800 | GROMMET | ₹ 13 | 1 | ||
| 50 | BK7F18750000 | CAP | ₹ 12 | 1 | ||
| 51 | BEPF18160000 | PIPE 1 | ₹ 32 | 1 | ||
| 52 | BEPF18170000 | PIPE 2 | ₹ 147 | 1 | ||
| 53 | 904670800300 | CLIP OIL PIPE | ₹ 8 | 2 | ||
| 54 | BLVF29570100 | BRACKET, HOSE | ₹ 160 | 1 | ||
| 55 | 958070601200 | BOLT FLANGE | ₹ 8 | 1 | ||
| 56 | 904640780500 | CLAMP | ₹ 20 | 3 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA BLV8 AEROX Series SIDE COVER
