WINDSHIELD
BPDD
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BCWF83810000 | WINDSHIELD | ₹ 398 | 1 | ||
| 2 | 901790580400 | NUT | ₹ 10 | 6 | ||
| 3 | BCWWF83500P3 | BODY COWNLING ASSY | ₹ 1278 | 1 | FOR WMC | |
| 4 | BCWF83910000 | GRAPHIC 1 | ₹ 93 | 1 | ||
| 5 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 6 | 901500502400 | SCREW ROUND HEAD | ₹ 59 | 6 | ||
| 7 | BCWF835G0000 | BODY FRONT UPPER 1 | ₹ 341 | 1 | ||
| 8 | 904801339800 | GROMMET | ₹ 10 | 1 | ||
| 9 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 10 | 977025001600 | SCREW TAPPING | ₹ 10 | 4 | ||
| 11 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 12 | 905200583800 | DAMPER PLATE | ₹ 8 | 2 | ||
| 13 | BCWF83560000 | STAY 1 | ₹ 1069 | 1 | ||
| 14 | 901050800200 | BOLT WASHER BASED | ₹ 8 | 2 | ||
| 15 | 904801356700 | GROMMET | ₹ 8 | 1 | ||
| 16 | BK7F62800000 | REAR VIEW MIRROR ASSY (LEFT) | ₹ 455 | 1 | ||
| 17 | BK7F62900000 | REAR VIEW MIRROR ASSY (RIGHT) | ₹ 455 | 1 | ||
| 18 | BCWF84830000 | PLATE RUBBER 1 | ₹ 28 | 2 | ||
| 19 | BCWF84840000 | PLATE RUBBER 2 | ₹ 180 | 1 | ||
| 20 | 913170603000 | BOLT | ₹ 15 | 4 | ||
| 21 | 903870613100 | COLLAR | ₹ 11 | 4 | ||
| 22 | BK7F16850000 | BRACKET LICENSE | ₹ 102 | 1 | ||
| 23 | 20PF34690000 | CAP BOLT | ₹ 2 | 4 | ||
| 24 | BCWF117V00P3 | COVER 7 | ₹ 1066 | 1 | FOR WMC | |
| 25 | 901830681800 | NUT SPRING | ₹ 23 | 1 | ||
| 26 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 27 | 904800155900 | GROMMET | ₹ 10 | 4 | ||
| 28 | 904801280500 | GROMMET | ₹ 8 | 1 | ||
| 29 | 903870689900 | COLLAR | ₹ 30 | 1 | ||
| 30 | 901490682900 | SCREW | ₹ 25 | 1 | ||
| 31 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 32 | BCWF172G0000 | PANEL 3 | ₹ 280 | 1 | ||
| 33 | 977025001600 | SCREW TAPPING | ₹ 10 | 4 | ||
| 34 | 904801356700 | GROMMET | ₹ 8 | 1 | ||
| 35 | 902690681300 | RIVET | ₹ 8 | 1 | ||
| 36 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 37 | 904801339800 | GROMMET | ₹ 10 | 1 | ||
| 38 | 903380718000 | PLUG | ₹ 84 | 1 | ||
| 39 | BCWF117W00P3 | COVER 8 | ₹ 1066 | 1 | FOR WMC | |
| 40 | 901830681800 | NUT SPRING | ₹ 23 | 1 | ||
| 41 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 42 | 904800155900 | GROMMET | ₹ 10 | 4 | ||
| 43 | 904801280500 | GROMMET | ₹ 8 | 1 | ||
| 44 | 903870689900 | COLLAR | ₹ 30 | 1 | ||
| 45 | 901490682900 | SCREW | ₹ 25 | 1 | ||
| 46 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 47 | BCWF172H0000 | PANEL 4 | ₹ 280 | 1 | ||
| 48 | 977025001600 | SCREW TAPPING | ₹ 10 | 4 | ||
| 49 | 904801356700 | GROMMET | ₹ 8 | 1 | ||
| 50 | 902690681300 | RIVET | ₹ 8 | 1 | ||
| 51 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 52 | 904801339800 | GROMMET | ₹ 10 | 1 | ||
| 53 | 903380718000 | PLUG | ₹ 84 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Aerodynamic efficiency defines the riding experience on the Yamaha R15M, thanks to the precision of this assembly. The Windshield redirects airflow to protect the rider from wind pressure during high speed runs. The Body Cownling Assy provides the sharp plus aggressive styling that makes this motorcycle a standout on Indian streets. Every Graphic One is designed with high quality adhesives to stay in place despite exposure to sun plus rain. Genuine components like the Rear View Mirror Assy offer a clear, stable view of the road behind you. Authentic replacements ensure a perfect fit that maintains the structural integrity of your fairing. This catalog includes every Nut Spring plus Grommet required for a secure installation. Experience the thrill of racing aesthetics with functional protection. Your motorcycle deserves the best aerodynamics available from the factory for peak performance during every single ride you take.
