LEG SHIELD
BPDT
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BCWXF836A000 | PANEL COMP 1 | ₹ 9098 | 1 | ||
| 2 | BPDF83934000 | GRAPHIC 3 | ₹ 200 | 1 | ||
| 3 | 904640701800 | CLAMP | ₹ 6 | 1 | ||
| 4 | 901830580700 | NUT SPRING | ₹ 9 | 5 | ||
| 5 | 901110685900 | BOLT HEX. SOCKET BUTTON | ₹ 7 | 1 | ||
| 6 | BCWXF83GA000 | PANEL COMP 2 | ₹ 9098 | 1 | ||
| 7 | BPDF83944000 | GRAPHIC 4 | ₹ 200 | 1 | ||
| 8 | 904640701800 | CLAMP | ₹ 6 | 1 | ||
| 9 | 901830580700 | NUT SPRING | ₹ 9 | 5 | ||
| 10 | 901110685900 | BOLT HEX. SOCKET BUTTON | ₹ 7 | 1 | ||
| 11 | BCWF837L0000 | PANEL CONSOLE 1 | ₹ 66 | 1 | ||
| 12 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 13 | BCWF837M0000 | PANEL CONSOLE 2 | ₹ 66 | 1 | ||
| 14 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 15 | BCWWF83800P3 | UNDER COVER ASSY.1 | ₹ 1783 | 1 | ||
| 16 | 992440020000 | EMBLEM YAMAHA | ₹ 762 | 1 | ||
| 17 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 18 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 19 | 904801280500 | GROMMET | ₹ 8 | 1 | ||
| 20 | 903870689900 | COLLAR | ₹ 30 | 1 | ||
| 21 | 901490682900 | SCREW | ₹ 25 | 1 | ||
| 22 | 901790684100 | NUT | ₹ 4 | 1 | ||
| 23 | BCWWF83900P3 | UNDER COVER ASSY 2 | ₹ 1783 | 1 | ||
| 24 | 992440020000 | EMBLEM YAMAHA | ₹ 762 | 1 | ||
| 25 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 26 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 27 | 904801280500 | GROMMET | ₹ 8 | 1 | ||
| 28 | 903870689900 | COLLAR | ₹ 30 | 1 | ||
| 29 | 901490682900 | SCREW | ₹ 25 | 1 | ||
| 30 | 901790684100 | NUT | ₹ 4 | 1 | ||
| 31 | BCWF836K0000 | PANEL INNER 1 | ₹ 132 | 1 | ||
| 32 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 33 | 903380718000 | PLUG | ₹ 84 | 1 | ||
| 34 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 35 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 36 | BCWF836L0000 | PANEL INNER 2 | ₹ 132 | 1 | ||
| 37 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 38 | 903380718000 | PLUG | ₹ 84 | 1 | ||
| 39 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 40 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 41 | BCWF836M0000 | PANEL INNER 3 | ₹ 286 | 1 | ||
| 42 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 4 | ||
| 43 | 902690681300 | RIVET | ₹ 8 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Defending the mechanical heart plus electrical components of your machine while providing sleek styling involves the authentic bodywork found in the Yamaha R15M Leg Shield assembly. This detailed catalog features every essential fairing piece including the primary Panel Comp units plus original Under Cover kits plus various Console panels today. Every specialized Graphic kit along with the required mounting Rivets plus Nut Springs plus Grommet sets ensures that the side body remains perfectly attached without vibrations. Using original Panels including Inner Panel plus Lower Cover units provides a perfectly flush fit against the frame while maintaining the streamlined airflow necessary for engine cooling. Yamaha R15M enthusiasts in India choose original fairing replacements because they feature high impact resistance plus UV protected paints that resist fading during several intense summers. Maintain the aggressive racing posture of your motorcycle by investing in authorized body panels today.
