FENDER
BPDY
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BNHXF15100P4 | FR.FENDER SUB ASSY | ₹ 1530 | 1 | FOR WMC | |
| 2 | 5TMF47862000 | EMBLEM - FAIRY SILVER | ₹ 28 | 1 | ||
| 3 | 90387068C800 | COLLAR | ₹ 16 | 6 | ||
| 4 | 904801280500 | GROMMET | ₹ 8 | 6 | ||
| 5 | 901110613700 | BOLT HEX. SOCKET BUTTON | ₹ 35 | 5 | ||
| 6 | BCWF16110000 | FENDER REAR | ₹ 170 | 1 | ||
| 7 | 901590681700 | SCREW, WITH WASHER | ₹ 10 | 2 | ||
| 8 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 9 | BK7F16290100 | GUARD MUD | ₹ 161 | 1 | ||
| 10 | BK7F834E0000 | DAMPER 1 | ₹ 14 | 2 | ||
| 11 | 90183050A700 | NUT SPRING | ₹ 22 | 4 | ||
| 12 | BK7F16170000 | BRACKET FENDER | ₹ 285 | 1 | ||
| 13 | 90387066J900 | COLLAR | ₹ 7 | 4 | ||
| 14 | BK7F16130000 | STAY FENDER 1 | ₹ 50 | 2 | ||
| 15 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 16 | 901190502200 | BOLT WITH WASHER | ₹ 3 | 4 | ||
| 17 | 901850680100 | NUT SELF-LOCKING | ₹ 5 | 4 | ||
| 18 | BCWF16420000 | GUARD FLAP | ₹ 47 | 1 | ||
| 19 | BGNF162R0000 | FENDER 2 | ₹ 295 | 1 | ||
| 20 | 901830403900 | NUT SPRING | ₹ 110 | 2 | ||
| 21 | 901730680600 | NUT, SQUARE | ₹ 11 | 1 | ||
| 22 | 901090622000 | BOLT | ₹ 19 | 2 | ||
| 23 | 902690681300 | RIVET | ₹ 8 | 1 | ||
| 24 | BK7F16410000 | BRACKET REFLECTOR | ₹ 35 | 1 | ||
| 25 | 902674884500 | RIVET BLIND | ₹ 9 | 1 | ||
| 26 | 2FCH51110000 | REFLECTOR FRONT 1 | ₹ 23 | 2 | ||
| 27 | 957070550000 | NUT FLANGE | ₹ 1 | 2 | ||
| 28 | 36LF81511100 | GRIP DRIVER | ₹ 9 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Protection against road spray plus debris is the primary role of the Fender assembly on the Yamaha R15M. This assembly includes the Front Fender Sub Assy plus the Fender Rear, both designed to complement the aggressive styling of the motorcycle. The Front Fender features the iconic Emblem plus is secured by Bolt Hex Socket Button hardware for a clean look. The rear section is supported by the Stay Fender plus various Guard Mud components to shield the rider plus the bike from water during rainy Indian weather. Additional features like the Guard Flap plus the Bracket Reflector ensure that the motorcycle meets all safety plus regulatory standards. Every Rivet plus Nut Spring is designed for a durable hold that resists the vibrations of high speed travel. Genuine Yamaha fenders ensure that your motorcycle remains clean plus protected while maintaining its aerodynamic efficiency plus premium finish.
