FENDER
BXF3
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | BCWF151100P4 | FENDER FRONT | ₹ 1531 | 1 | FOR SMX | |
| 1B | BCWF151100P1 | FENDER, FRONT | ₹ 1599 | 1 | FOR DPBMY | |
| 1C | BCWF1511003E | FENDER, FRONT | ₹ 1599 | 1 | FOR PGD | |
| 1D | BCWF151100P6 | FENDER, FRONT | ₹ 1599 | 1 | FOR MLNM4 | |
| 2 | 90387068C800 | COLLAR | ₹ 16 | 6 | ||
| 3 | 904801280500 | GROMMET | ₹ 8 | 6 | ||
| 4 | 901110613700 | BOLT HEX. SOCKET BUTTON | ₹ 35 | 5 | ||
| 5 | BCFF16110000 | FENDER REAR | ₹ 139 | 1 | ||
| 6 | 905600832600 | SPACER | ₹ 10 | 4 | ||
| 7 | 901090622000 | BOLT | ₹ 19 | 2 | ||
| 8 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 9 | BCFH19750000 | PLATE RECTIFIER FITTING | ₹ 95 | 1 | ||
| 10 | BXFF16820000 | STAY, PLATE | ₹ 115 | 1 | ||
| 11 | 901850680100 | NUT SELF-LOCKING | ₹ 5 | 2 | ||
| 12 | 958220601200 | BOLT FLANGE | ₹ 3 | 2 | ||
| 13 | 902690681200 | RIVET | ₹ 20 | 2 | ||
| 14 | 901830606900 | NUT SPRING | ₹ 159 | 2 | ||
| 15 | B9DF16290100 | GUARD MUD | ₹ 82 | 1 | ||
| 16 | B9DF16400000 | REAR STAY COMP. | ₹ 599 | 1 | ||
| 17 | 977025001600 | SCREW TAPPING | ₹ 10 | 2 | ||
| 18 | 90183050A700 | NUT SPRING | ₹ 22 | 2 | ||
| 19 | 901190502200 | BOLT WITH WASHER | ₹ 3 | 2 | ||
| 20 | B9DF163A0000 | COVER REAR FENDER 1 | ₹ 54 | 1 | ||
| 21 | B9DF465B0100 | CAP ROTOR | ₹ 6 | 1 | ||
| 22 | 902410380000 | PIN | ₹ 8 | 1 | ||
| 23 | 905080900700 | SPRING TORSION | ₹ 45 | 1 | ||
| 24 | 901830301000 | NUT SPRING | ₹ 9 | 1 | ||
| 25 | 901850680100 | NUT SELF-LOCKING | ₹ 5 | 4 | ||
| 26 | 905200880400 | DAMPER PLATE | ₹ 13 | 1 | ||
| 27 | B9DF13910000 | BRACKET SEAT | ₹ 195 | 1 | ||
| 28 | 2FCH51110000 | REFLECTOR FRONT 1 | ₹ 23 | 2 | ||
| 29 | 957070550000 | NUT FLANGE | ₹ 1 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Protection from road spray and debris is essential for maintaining the clean look and functionality of your Yamaha MT15 V2 during every ride. This catalog features the Front Fender and the Rear Fender Comp, which are designed to channel water and mud away from the rider and engine. Included in this selection are the Mud Guard and the various Stay and Plate components that ensure the fenders remain securely in place on rough roads. Every Bolt and Nut Spring is manufactured to withstand the constant vibrations and environmental stresses of daily commuting in various weather conditions. The Rear Stay Comp and specialized Reflector Front are critical for both structural support and safety, ensuring your motorcycle remains visible to other motorists. By choosing genuine Yamaha fender parts, you maintain the high quality finish and protective capabilities of your machine. Trust in original equipment for a perfect fit that keeps your motorcycle looking sharp and your journey much cleaner.
