INTAKE
D521
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B9PE35852000 | MANIFOLD | ₹ 208 | 1 | ||
| 2 | 913120602500 | BOLT | ₹ 7 | 2 | ||
| 3 | 2GSE36450000 | GASKET MANIFOLD 1 | ₹ 30 | 1 | ||
| 4 | BACE37700000 | INJECTOR ASSY | ₹ 2681 | 1 | ||
| 5 | BACE41A10000 | SEAL RING | ₹ 145 | 1 | ||
| 6 | 958120603000 | BOLT FLANGE | ₹ 14 | 1 | ||
| 7 | 904504380800 | HOSE CLAMP ASSY | ₹ 30 | 1 | ||
| 8 | B9PE42430000 | PLATE | ₹ 21 | 1 | ||
| 9 | B9PE36460000 | GASKET MANIFOLD 2 | ₹ 39 | 1 | ||
| 10 | 901100684600 | BOLT HEXAGON SOCKET HEAD | ₹ 44 | 2 | ||
| 11 | B9PE37500100 | THROTTLE BODY ASSY | ₹ 4254 | 1 | ||
| 12 | B9PE44110000 | CASE AIR CLEANER 1 | ₹ 590 | 1 | ||
| 13 | B9PE44121000 | CAP CLEANER CASE 1 | ₹ 220 | 1 | ||
| 14 | B9PE44500000 | ELEMENT ASSY AIR CLEANER | ₹ 245 | 1 | ||
| 15 | B9PE44530000 | JOINT AIR CLEANER 1 | ₹ 195 | 1 | ||
| 16 | 2GSE44520000 | SEAL | ₹ 32 | 1 | ||
| 17 | 20PE443E0000 | PIPE DRAIN | ₹ 11 | 1 | ||
| 18 | 904671280000 | CLIP | ₹ 12 | 1 | ||
| 19 | 977025002500 | SCREW TAPPING | ₹ 10 | 9 | ||
| 20 | 903870673700 | COLLAR | ₹ 11 | 1 | ||
| 21 | 903870980600 | COLLAR | ₹ 11 | 2 | ||
| 22 | 958270801600 | BOLT FLANGE | ₹ 10 | 3 | ||
| 23 | 2GSE11661000 | PIPE BREATHER 1 | ₹ 40 | 1 | ||
| 24 | 904671381600 | CLIP | ₹ 4 | 1 | ||
| 25 | 904671501200 | CLIP | ₹ 5 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Providing a precise mixture of air plus fuel is critical for engine efficiency, plus this intake assembly is engineered for that exact task. Featuring the high precision Injector Assy plus the sophisticated Throttle Body Assy, it ensures that every combustion cycle is optimized for power plus economy. The Manifold plus Gasket Manifold provide a secure plus airtight path for intake air, while the Case Air Cleaner with its high performance Element Assy Air Cleaner removes dust plus debris. Securely held by the Hose Clamp Assy plus various Clip components, the system remains reliable under all engine loads. The inclusion of the Pipe Breather plus Pipe Drain ensures the system stays clean plus free from moisture. Every Bolt Flange plus Collar is designed for a perfect fit, providing the reliability needed for consistent performance. This intake system is the key to the responsive throttle feel that makes your motorcycle a joy to ride in any traffic or on any highway.
