REAR WHEEL
D521
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BPDF533800P8 | CAST WHEEL, REAR | ₹ 7868 | 1 | FOR MT2 | |
| 2 | B97F530S0000 | COLLAR ASSY | ₹ 49 | 1 | ||
| 3 | 931062280800 | OIL SEAL | ₹ 9 | 1 | ||
| 4 | B97F53640000 | DAMPER | ₹ 25 | 6 | ||
| 5 | 93306202XT00 | BEARING ( USE IN REAR WHEEL H | ₹ 185 | 2 | ||
| 6 | B97F53660000 | CLUTCH HUB | ₹ 456 | 1 | ||
| 7 | 93306054Y500 | BEARING | ₹ 170 | 1 | ||
| 8 | B97F53760000 | COLLAR WHEEL | ₹ 41 | 1 | ||
| 9 | 931062680100 | SEAL OIL | ₹ 23 | 1 | ||
| 10 | 2GSF54411000 | SPROCKET, DRIVEN (41T) | ₹ 0 | 1 | ||
| 11 | 901160882600 | BOLT STUD | ₹ 31 | 6 | ||
| 12 | 956020820000 | NUT U FLANGE | ₹ 11 | 6 | ||
| 13 | 941141781800 | TIRE (140/60-R17 63P) | ₹ 0 | 1 | ||
| 14 | 939000082400 | VALVE RIM | ₹ 19 | 1 | ||
| 15 | B9EF517G0000 | ROTOR SENSOR | ₹ 107 | 1 | ||
| 16 | 901490503000 | SCREW | ₹ 21 | 3 | ||
| 17 | 21CF53810000 | AXLE WHEEL | ₹ 147 | 1 | ||
| 18 | B97F53770000 | COLLAR WHEEL | ₹ 31 | 1 | ||
| 19 | B97F53830000 | COLLAR WHEEL | ₹ 38 | 1 | ||
| 20 | 901851480000 | NUT SELF-LOCKING | ₹ 28 | 1 | ||
| 21 | 902011581400 | WASHER PLAIN | ₹ 27 | 2 | ||
| 22A | 94568K312800 | CHAIN (R428NAR 128L) | ₹ 0 | 1 | ||
| 22B | 94568L712800 | 94568L712800 | ₹ 0 | 1 | ||
| 23 | 21CF53881100 | PULLER CHAIN 1 | ₹ 55 | 2 | ||
| 24 | 21CF21740000 | END 1 | ₹ 9 | 2 | ||
| 25 | 929070860000 | WASHER | ₹ 8 | 2 | ||
| 26 | 9530N0860000 | NUT HEX | ₹ 5 | 4 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Powering through the landscape requires a rear wheel assembly that can handle both the engine torque plus the varied road surfaces of India. This setup features the high strength Rear Wheel plus the precision Sprocket Driven, which together provide smooth plus reliable power delivery. Internal components like the Bearing plus Oil Seal are engineered for low friction rotation plus maximum durability against environmental contaminants. The Damper plus Clutch Hub absorb the shocks of acceleration plus gear changes, protecting your drivetrain. Secured by the Axle Wheel plus Nut Self Locking, the assembly remains perfectly aligned for a stable ride. The high traction Tire provides excellent grip, while the Rotor Sensor ensures accurate data for your motorcycle safety systems. Every Washer plus Nut is chosen for its ability to withstand the stresses of high speed travel, making this wheel assembly a perfect blend of performance plus mechanical integrity.
