FRONT WHEEL
D631/D641
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | B9EF5168018L | CAST WHEEL FRONT | ₹ 5019 | 1 | FOR SMX,DRMK | |
| 1B | B9EF516801P0 | CAST WHEEL FRONT | ₹ 5019 | 1 | FOR PGD | |
| 2 | 21CF510C1000 | COLLAR ASSY. | ₹ 27 | 1 | ||
| 3 | 931062280800 | OIL SEAL | ₹ 9 | 2 | ||
| 4 | 93306202XT00 | BEARING ( USE IN REAR WHEEL H | ₹ 185 | 2 | ||
| 5A | 941101781800 | TIRE FRONT ( 100/80-17 ) MRF | ₹ 1751 | 1 | ||
| 5B | 941101782400 | TIRE | ₹ 0 | 1 | ||
| 6 | 939000082400 | VALVE RIM | ₹ 19 | 1 | ||
| 7 | B9EF517G0000 | ROTOR SENSOR | ₹ 107 | 1 | ||
| 8 | 901490503000 | SCREW | ₹ 21 | 3 | ||
| 9 | 1CKF51860000 | COLLAR WHEEL | ₹ 23 | 2 | ||
| 10 | 21CF51810000 | AXLE WHEEL | ₹ 152 | 1 | ||
| 11 | 901851480000 | NUT SELF-LOCKING | ₹ 28 | 1 | ||
| 12 | 929071420000 | WASHER | ₹ 8 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The steering agility plus directional stability of your Yamaha FZS V4 depend on the integrity of the Front Wheel assembly. The Cast Wheel Front is manufactured to be lightweight yet robust enough to handle the impacts of city potholes across India. Rotating on precision Bearings plus sealed with a high grade Oil Seal, the wheel provides an effortless plus smooth rolling experience for the rider. For the ultimate grip, the MRF Tire is designed to channel water away plus maintain a solid contact patch in both wet plus dry conditions. The Rotor Sensor works in conjunction with the ABS system to monitor rotational speed plus prevent front wheel lock up. Every Axle Wheel plus Nut Self Locking ensures that the front end remains perfectly aligned for a vibration free ride. Using genuine wheel components is essential for maintaining the light plus responsive handling characteristics that define the machine. Trust in authentic parts for a safe plus comfortable journey through every turn.
