FUEL TANK 2
D705/D735
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 901600580800 | SCREW, ROUND TAPPING | ₹ 7 | 2 | ||
| 2A | B4GXF41200PD | TANK SIDE COVER 1 | ₹ 1500 | 1 | FOR MT2 | |
| 2B | B4GXF41260P0 | TANK SIDE COVER 1 | ₹ 1500 | 1 | FOR SMX | |
| 3 | BGPF817K0000 | LABEL FUEL | ₹ 10 | 1 | ||
| 4 | B4GF413B0000 | EMBLEM | ₹ 37 | 1 | ||
| 5A | D70F42442000 | GRAPHIC, FUEL TANK 1 | ₹ 150 | 1 | FOR MT2 | |
| 5B | D70F42443000 | GRAPHIC, FUEL TANK 1 | ₹ 150 | 1 | FOR SMX | |
| 6A | D70F42460000 | GRAPHIC 3 | ₹ 100 | 1 | FOR MT2 | |
| 6B | D70F42461000 | GRAPHIC 3 | ₹ 100 | 1 | FOR SMX | |
| 7 | 904800155900 | GROMMET | ₹ 10 | 1 | ||
| 8 | 901830580700 | NUT SPRING | ₹ 9 | 3 | ||
| 9 | 958220602000 | BOLT FLANGE | ₹ 5 | 1 | ||
| 10 | 20PF17490000 | COLLAR | ₹ 4 | 1 | ||
| 11 | 904800181100 | GROMMET | ₹ 8 | 1 | ||
| 12 | B4GF836K0000 | PANEL INNER 1 | ₹ 106 | 1 | ||
| 13 | B4GF83960000 | PLATE 1 | ₹ 49 | 1 | ||
| 14 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 5 | ||
| 15 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 1 | ||
| 16 | B4GF837N10P0 | GRILL AIR INTAKE 1 MBL2 | ₹ 282 | 1 | ||
| 17A | B4GXF41300PD | TANK SIDE COVER 2 | ₹ 1500 | 1 | FOR MT2 | |
| 17B | B4GXF41360P0 | TANK SIDE COVER 2 | ₹ 1500 | 1 | FOR SMX | |
| 18 | B4GF413B0000 | EMBLEM | ₹ 37 | 1 | ||
| 19A | D70F42452000 | GRAPHIC, FUEL TANK 2 | ₹ 150 | 1 | FOR MT2 | |
| 19B | D70F42453000 | GRAPHIC, FUEL TANK 2 | ₹ 150 | 1 | FOR SMX | |
| 20A | D70F42470000 | GRAPHIC | ₹ 100 | 1 | FOR MT2 | |
| 20B | D70F42471000 | GRAPHIC | ₹ 100 | 1 | FOR SMX | |
| 21 | 904800155900 | GROMMET | ₹ 10 | 1 | ||
| 22 | 901830580700 | NUT SPRING | ₹ 9 | 3 | ||
| 23 | 958220602000 | BOLT FLANGE | ₹ 5 | 1 | ||
| 24 | 20PF17490000 | COLLAR | ₹ 4 | 1 | ||
| 25 | 904800181100 | GROMMET | ₹ 8 | 1 | ||
| 26 | B4GF836L0000 | PANEL INNER 2 | ₹ 106 | 1 | ||
| 27 | B4GF83970000 | PLATE 2 | ₹ 49 | 1 | ||
| 28 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 5 | ||
| 29 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 1 | ||
| 30 | B4GF837R10P0 | GRILL AIR INTAKE 2 MBL2 | ₹ 282 | 1 | ||
| 31 | B9PF411H0000 | HOOK SIDE COVER 2 | ₹ 117 | 1 | ||
| 32 | 45SF17780000 | DAMPER LOCATING 1 | ₹ 8 | 1 | ||
| 33 | 958120601200 | BOLT FLANGE | ₹ 3 | 1 | ||
| 34 | B4GF41240000 | AIR SHROUD | ₹ 87 | 1 | ||
| 35 | 903870604800 | COLLAR | ₹ 7 | 2 | ||
| 36 | 958270601400 | BOLT FLANGE | ₹ 18 | 2 | ||
| 37 | 2GSF43640000 | STAY | ₹ 8 | 1 | ||
| 38 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 39 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 4 | ||
| 40 | B4GF137U0000 | GUIDE AIR 1 | ₹ 80 | 1 | ||
| 41 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 42 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 1 | ||
| 43 | B4GF137W00P0 | SCOOP AIR 1 SMX | ₹ 202 | 1 | ||
| 44 | 901830580700 | NUT SPRING | ₹ 9 | 3 | ||
| 45 | BFJF137V0000 | GUIDE, AIR 2 | ₹ 138 | 1 | ||
| 46 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 47 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 1 | ||
| 48 | B4GF137X00P0 | SCOOP AIR 2 SMX | ₹ 193 | 1 | ||
| 49 | 901830580700 | NUT SPRING | ₹ 9 | 3 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The aggressive personality of the Yamaha FZ RAVE is highlighted by the Fuel Tank Two assembly which features the outer body panels. These components include the Panel Inner plus the Grill Air Intake which give the bike its muscular shoulder look. The assembly is adorned with the iconic Tuning Fork Emblem plus specific Label Fuel for a factory finish. Every Nut Spring plus Bolt Flange ensures that the covers remain rattle free during high speed operation. The Air Shroud plus Scoop Air are designed to channel cool air toward the engine to assist in heat dissipation. These panels are secured using specialized Screw Truss Hd Tap plus resilient Grommet hardware. The stay plus collar components ensure that the bodywork remains perfectly aligned with the frame. Using genuine covers ensures a perfect color match plus impact resistance. This assembly represents the outer skin that defines the streetfighter aesthetic of the motorcycle. It protects the internal fuel reservoir while enhancing style.
