REAR MASTER CYLINDER
D705/D735
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BFJF580E0000 | REAR MASTER CYLINDER ASSY | ₹ 2074 | 1 | ||
| 2 | BPDF583V0000 | RR. MASTER CYLINDE | ₹ 2198 | 1 | ||
| 3 | BPDF58080000 | CYLINDER KIT, MAST | ₹ 562 | 1 | ||
| 4 | BPDWF7220000 | PUSH ROD SET | ₹ 387 | 1 | ||
| 5 | BPDWF5820000 | CONNECTOR AND BUSH SET | ₹ 27 | 1 | ||
| 6 | BFJF58950000 | HOSE, RESERVOIR | ₹ 105 | 1 | ||
| 7 | BPDF72680000 | CLIP, WIRE | ₹ 36 | 2 | ||
| 8 | BPDF58045000 | RESERVE TANK ASSY. | ₹ 92 | 1 | ||
| 9 | 902400800500 | PIN CLEVIS | ₹ 52 | 1 | ||
| 10 | 902521880000 | PIN SPLIT | ₹ 1 | 1 | ||
| 11 | 920120802000 | BOLT BUTTON HEAD | ₹ 20 | 2 | ||
| 12 | BK7F47420000 | GROMMET | ₹ 10 | 1 | ||
| 13 | BK7F62590000 | COLLAR | ₹ 42 | 1 | ||
| 14 | 902010682800 | WASHER PLATE | ₹ 4 | 1 | ||
| 15 | 958020602500 | BOLT FLANGE | ₹ 6 | 1 | ||
| 16 | BFJF58730000 | HOSE, BRAKE 2 | ₹ 750 | 1 | ||
| 17 | 904011001500 | BOLT UNION | ₹ 34 | 2 | ||
| 18 | 902011011800 | WASHER PLAIN | ₹ 5 | 4 | ||
| 19 | 904641700300 | CLAMP | ₹ 83 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Precise control over the rear braking system of the Yamaha FZ RAVE begins with the Rear Master Cylinder assembly. This hydraulic module features the primary Rear Master Cylinder Assy which translates pedal pressure into stopping force. The internal Cylinder Kit Mast plus Pushing Rod Set ensure a consistent plus progressive feel during braking maneuvers. Fluid is stored within the Reserve Tank Assy which is connected via a durable Hose Reservoir plus specific Clip. For safety, the assembly includes a Pin Clevis together with a Pin Split to secure the mechanical linkage. Every Bolt Union plus Washer Plain ensures a leak proof hydraulic connection to the brake caliper. This module is vital for maintaining the balance of the motorcycle during deceleration. High quality seals prevent the entry of air into the system which would otherwise cause a spongy pedal. This assembly provides the reliable hydraulic pressure needed for confident riding on all surfaces.
