REAR WHEEL
D705/D735
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BFJF533800P0 | CAST WHEEL, REAR | ₹ 7710 | 1 | ||
| 2 | B97F530S0000 | COLLAR ASSY | ₹ 49 | 1 | ||
| 3 | 931062280800 | OIL SEAL | ₹ 9 | 1 | ||
| 4 | B97F53640000 | DAMPER | ₹ 25 | 6 | ||
| 5 | 93306202XT00 | BEARING ( USE IN REAR WHEEL H | ₹ 185 | 2 | ||
| 6 | B97F53660000 | CLUTCH HUB | ₹ 456 | 1 | ||
| 7 | 93306054Y500 | BEARING | ₹ 170 | 1 | ||
| 8 | B97F53760000 | COLLAR WHEEL | ₹ 41 | 1 | ||
| 9 | 931062680100 | SEAL OIL | ₹ 23 | 1 | ||
| 10 | 2GSF54411000 | SPROCKET, DRIVEN (41T) | ₹ 0 | 1 | ||
| 11 | 901160882600 | BOLT STUD | ₹ 31 | 6 | ||
| 12 | 956020820000 | NUT U FLANGE | ₹ 11 | 6 | ||
| 13A | 941141780100 | TIRE | ₹ 0 | 1 | ||
| 13B | 941141780700 | TIRE -REAR-CEAT LIMITED | ₹ 2939 | 1 | ||
| 14 | 939000082400 | VALVE RIM | ₹ 19 | 1 | ||
| 15 | 21CF53810000 | AXLE WHEEL | ₹ 147 | 1 | ||
| 16 | B97F53770000 | COLLAR WHEEL | ₹ 31 | 1 | ||
| 17 | B97F53830000 | COLLAR WHEEL | ₹ 38 | 1 | ||
| 18 | 901851480000 | NUT SELF-LOCKING | ₹ 28 | 1 | ||
| 19 | 902011581400 | WASHER PLAIN | ₹ 27 | 2 | ||
| 20 | 94568K312800 | CHAIN (R428NAR 128L) | ₹ 0 | 1 | ||
| 21 | 21CF53881100 | PULLER CHAIN 1 | ₹ 55 | 2 | ||
| 22 | 21CF21740000 | END 1 | ₹ 9 | 2 | ||
| 23 | 929070860000 | WASHER | ₹ 8 | 2 | ||
| 24 | 9530N0860000 | NUT HEX | ₹ 5 | 4 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The delivery of power to the ground for the Yamaha FZ RAVE occurs through the robust Rear Wheel assembly. This unit features a high strength wheel together with the Clutch Hub which houses the vibration dampening Damper. High quality Bearings plus Oil Seals ensure that the wheel rotates with minimal friction for better fuel efficiency. The drive is managed by the Sprocket Driven Forty One Teeth together with the Chain R428nar 128l. Every Bolt Stud plus Nut U Flange ensures a secure connection for the drivetrain components. The Axle Wheel provides the central support while the Puller Chain ensures precise adjustment of the chain tension. This assembly is designed to handle the torque of the engine while providing a stable ride. The Valve Rim ensures the tire remains properly inflated for optimal grip. Authentic wheel parts are essential for the safety plus performance of the motorcycle. It represents the final link in the power transmission system.
