FUEL TANK 2
D734
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 901600580800 | SCREW, ROUND TAPPING | ₹ 7 | 2 | ||
| 2A | BNMXF41210P0 | TANK SIDE COVER 1 | ₹ 1576 | 1 | FOR SMX | |
| 2B | BNMXF41200PA | TANK SIDE COVER 1 | ₹ 1576 | 1 | FOR CM7 | |
| 3 | B4GF413B0000 | EMBLEM | ₹ 37 | 1 | ||
| 4A | D70F42440000 | GRAPHIC, FUEL TANK 1 | ₹ 75 | 1 | FOR SMX | |
| 4B | D70F42441000 | GRAPHIC, FUEL TANK 1 | ₹ 75 | 1 | FOR CM7 | |
| 5 | BGPF817K0000 | LABEL FUEL | ₹ 10 | 1 | ||
| 6 | 904800155900 | GROMMET | ₹ 10 | 1 | ||
| 7 | 901830580700 | NUT SPRING | ₹ 9 | 3 | ||
| 8 | 958220602000 | BOLT FLANGE | ₹ 5 | 1 | ||
| 9 | 20PF17490000 | COLLAR | ₹ 4 | 1 | ||
| 10 | 904800181100 | GROMMET | ₹ 8 | 1 | ||
| 11 | B4GF836K0000 | PANEL INNER 1 | ₹ 106 | 1 | ||
| 12 | B4GF83960000 | PLATE 1 | ₹ 49 | 1 | ||
| 13 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 5 | ||
| 14 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 1 | ||
| 15 | B4GF837N10P0 | GRILL AIR INTAKE 1 MBL2 | ₹ 282 | 1 | ||
| 16A | BNMXF41310P0 | TANK SIDE COVER 2 | ₹ 1576 | 1 | FOR SMX | |
| 16B | BNMXF41300PA | TANK SIDE COVER 2 | ₹ 1576 | 1 | FOR CM7 | |
| 17 | B4GF413B0000 | EMBLEM | ₹ 37 | 1 | ||
| 18A | D70F42450000 | GRAPHIC, FUEL TANK 2 | ₹ 75 | 1 | FOR SMX | |
| 18B | D70F42451000 | GRAPHIC, FUEL TANK 2 | ₹ 75 | 1 | FOR CM7 | |
| 19 | 904800155900 | GROMMET | ₹ 10 | 1 | ||
| 20 | 901830580700 | NUT SPRING | ₹ 9 | 3 | ||
| 21 | 958220602000 | BOLT FLANGE | ₹ 5 | 1 | ||
| 22 | 20PF17490000 | COLLAR | ₹ 4 | 1 | ||
| 23 | 904800181100 | GROMMET | ₹ 8 | 1 | ||
| 24 | B4GF836L0000 | PANEL INNER 2 | ₹ 106 | 1 | ||
| 25 | B4GF83970000 | PLATE 2 | ₹ 49 | 1 | ||
| 26 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 5 | ||
| 27 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 1 | ||
| 28 | B4GF837R10P0 | GRILL AIR INTAKE 2 MBL2 | ₹ 282 | 1 | ||
| 29 | B9PF411H0000 | HOOK SIDE COVER 2 | ₹ 117 | 1 | ||
| 30 | 45SF17780000 | DAMPER LOCATING 1 | ₹ 8 | 1 | ||
| 31 | 958120601200 | BOLT FLANGE | ₹ 3 | 1 | ||
| 32 | B4GF41240000 | AIR SHROUD | ₹ 87 | 1 | ||
| 33 | 903870604800 | COLLAR | ₹ 7 | 2 | ||
| 34 | 958270601400 | BOLT FLANGE | ₹ 18 | 2 | ||
| 35 | 2GSF43640000 | STAY | ₹ 8 | 1 | ||
| 36 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 37 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 4 | ||
| 38 | B4GF137U0000 | GUIDE AIR 1 | ₹ 80 | 1 | ||
| 39 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 40 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 1 | ||
| 41A | B4GF137W00P4 | SCOOP AIR 1 MNM3 | ₹ 212 | 1 | FOR SMX | |
| 41B | B4GF137W00P9 | SCOOP, AIR 1 | ₹ 175 | 1 | FOR CM7 | |
| 42 | 901830580700 | NUT SPRING | ₹ 9 | 3 | ||
| 43 | BFJF137V0000 | GUIDE, AIR 2 | ₹ 138 | 1 | ||
| 44 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 45 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 1 | ||
| 46A | B4GF137X00P4 | SCOOP AIR 2 MNM3 | ₹ 212 | 1 | FOR SMX | |
| 46B | B4GF137X00P9 | SCOOP, AIR 2 | ₹ 175 | 1 | FOR CM7 | |
| 47 | 901830580700 | NUT SPRING | ₹ 9 | 3 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Aesthetics meet functionality in the sculpting of the motorcycle body, where the fuel tank covers define the aggressive, muscular character. This side cover, shroud assembly is designed to give the bike its iconic street fighter look while managing airflow. The tank side cover plus air shroud are crafted from premium materials that offer a perfect fit, high finish. Adding to the visual appeal are genuine emblems plus graphics designed to resist fading, peeling under the harsh Indian sun. Functional elements like the grill air intake plus scoop air ensure the engine receives a steady stream of cooling air. Every panel inner plus plate is secured with a combination of a grommet plus a nut spring, ensuring a vibration free fit. By replacing these body parts with genuine units, you maintain the showroom appearance of your motorcycle while ensuring all aerodynamic features function exactly as the engineers intended.
