OIL PUMP
D734
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 54BE33000000 | OIL PUMP ASSY | ₹ 130 | 1 | ||
| 2 | 901110503500 | BOLT HEX. SOCKET BUTTON | ₹ 17 | 2 | ||
| 3 | 903401280800 | PLUG STRAIGHT SCREW | ₹ 12 | 1 | ||
| 4 | 904301222700 | GASKET | ₹ 4 | 1 | ||
| 5 | 4LSE34110000 | STRAINER OIL | ₹ 30 | 1 | ||
| 6 | 21CE34400100 | ELEMENT ASSY OIL CLEANER | ₹ 80 | 1 | ||
| 7 | 21CE34470000 | COVER ELEMENT | ₹ 136 | 1 | ||
| 8 | 950220602000 | BOLT FLANGE | ₹ 15 | 2 | ||
| 9 | 950220606500 | BOLT, FLANGE | ₹ 32 | 1 | ||
| 10 | 21CE34490000 | GASKET ELEMENT COVER | ₹ 44 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Lubrication is the lifeblood of your engine, the oil pump is the heart that keeps it circulating. This oil pump assembly is responsible for providing necessary oil pressure to every moving part, from the crankshaft to the valve train. The set includes a robust oil pump assy plus a strainer oil that filters out large particles before oil enters the system. Protecting the delicate internals of the pump are specialized gaskets plus a high quality oil cleaner element. Every bolt flange plus button head bolt is manufactured to ensure the pump stays securely mounted, preventing any loss of pressure. This system is crucial for managing engine temperature in the extreme Indian summers, where oil must flow freely despite the heat. By using these genuine oil pump components, you ensure the internal health plus longevity of your motorcycle's motor. Trust in the reliability of a lubricated engine for city commutes.
