STARTING MOTOR
D734
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2GSH18001300 | STARTING MOTOR ASSY | ₹ 1834 | 1 | ||
| 2 | 2SPH18281100 | BOLT 2 | ₹ 65 | 2 | ||
| 3 | 2SPH18341000 | RING | ₹ 12 | 1 | ||
| 4 | 2GSH183G0000 | CORD COMP. | ₹ 525 | 1 | ||
| 5 | 2SPH18011000 | BRUSH SET | ₹ 97 | 1 | ||
| 6 | 913120602000 | BOLT HEXAGON SOCKET HEAD | ₹ 38 | 2 | ||
| 7 | 932102980700 | O-RING | ₹ 8 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The journey of a thousand miles begins with the simple push of a button, the starting motor is the force that makes it happen. This powerful assembly is the heavy lifter of the engine, providing the initial torque needed to bring the piston to life. Featuring a high quality starting motor assy plus a durable brush set, the system ensures consistent cranking even after the bike has been idle for days. Every internal part, including the bolt hexagon socket head, the sealing o-ring, is engineered to operate in the high heat environment near the crankcase. The cord comp facilitates efficient power delivery from the battery to the motor, minimizing energy loss during the start cycle. By maintaining this component with genuine parts, you avoid the frustration of a stalled engine plus the inconvenience of manual starting. Ensure your motorcycle is always ready to go at a moment's notice.
