VALVE

D734

YAMAHA D734 FZ V3 Series VALVE
Fullscreen
Ref No Part No Part Name Rate Qnty Order Remarks
1 2GSE21110000 VALVE INTAKE ₹ 110 1
2 2GSE21210000 VALVE EXHAUST ₹ 212 1
3 38BE21190000 SEAL VALVE STEM ₹ 30 2
4 2GSE21260000 SEAT VALVE SPRING 2 ₹ 18 2
5 2GSE21131000 SPRING VALVE INNER ₹ 70 2
6 3S0E21180000 COTTER VALVE ₹ 9 4
7 2UPE21170000 RETAINER VALVE SPRING ₹ 65 2
8 52SE21691000 PAD ADJUSTING ₹ 129 2
9 1STE21510000 ARM VALVE ROCKER ₹ 262 2
10 2GSE21590000 SCREW VALVE ADJUSTING ₹ 101 2
11 901700530200 NUT ₹ 7 2
12 21CE21560000 SHAFT ROCKER 2 ₹ 36 2
13 913120501600 BOLT ₹ 5 2


Color Legend:

  • Red: Canceled part - unavailable for any operations.
  • Blue: Part of a kit - cannot be ordered individually.
  • Gray (Dimmed): Disabled part - non-interactive for various reasons.
  • Part Number : Superseded part - replaced by a newer part.

Description: - Breathe life into your engine with a valve system that operates with surgical precision thousands of times per minute. This assembly contains the intake valve plus exhaust valve, critical components that manage the flow of gases in, out of the combustion chamber. To ensure an airtight seal plus prevent oil leakage, a specialized seal valve stem, retainer are used. The movement is controlled by the rocker arm, its shaft, which transmit the cam profile with minimal friction. Every detail, from the cotter valve to the adjusting pad, is engineered to withstand extreme heat, pressure within the cylinder head. Regular maintenance using these genuine components ensures your engine retains its compression plus power output over time. For the Indian rider, this translates to better fuel efficiency plus a more responsive motor. Trust in these factory grade parts to keep your motorcycle breathing perfectly, providing the legendary performance you depend on.
