CYLINDER HEAD
D782
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B2XE11020100 | CYLINDER HEAD ASSY | ₹ 33325 | 1 | ||
| 2 | 1WDE11331000 | GUIDE VALVE 1(O/S)-EXHAUST | ₹ 705 | 8 | ||
| 3 | 901050602700 | BOLT FLANGE | ₹ 15 | 12 | ||
| 4 | 903401800200 | PLUG STRAIGHT SCREW | ₹ 175 | 1 | ||
| 5 | 950220801200 | BOLT FLANGE | ₹ 9 | 1 | ||
| 6 | 904300880300 | GASKET | ₹ 5 | 1 | ||
| 7 | 956120862500 | BOLT, STUD | ₹ 75 | 4 | ||
| 8 | 2MS113610000 | BOLT, CYLINDER HOLDING 1 | ₹ 310 | 6 | ||
| 9 | 902011084500 | WASHER, PLATE | ₹ 70 | 6 | ||
| 10 | 901100687000 | BOLT, HEXAGON SOCKET HEAD | ₹ 35 | 2 | ||
| 11 | 947000043600 | SPARK PLUG-NGK | ₹ 1198 | 2 | ||
| 12 | BR5E11810000 | GASKET, CYLINDER HEAD 1 | ₹ 1120 | 1 | ||
| 13 | 995301401600 | PIN DOWEL | ₹ 5 | 2 | ||
| 14 | 901090689800 | BOLT | ₹ 75 | 1 | ||
| 15 | 1WDE111G0000 | RUBBER, MOUNT 1 | ₹ 212 | 1 | ||
| 16 | B1XE11910000 | COVER, CYLINDER HEAD 1 | ₹ 2424 | 1 | ||
| 17 | B1XE11930000 | GASKET, HEAD COVER 1 | ₹ 1175 | 1 | ||
| 18 | B1XE11950000 | GASKET | ₹ 100 | 2 | ||
| 19 | 5VY1482K0000 | PLATE | ₹ 96 | 2 | ||
| 20 | 1WDE48900000 | REED VALVE ASSY | ₹ 717 | 1 | ||
| 21 | 1WDE48990000 | CAP CASE | ₹ 175 | 1 | ||
| 22 | 913320602000 | BOLT | ₹ 5 | 2 | ||
| 23 | 1WDE22410100 | GUIDE, STOPPER 2 | ₹ 147 | 1 | ||
| 24 | 901090689900 | BOLT | ₹ 40 | 4 | ||
| 25 | 1WDE111G0000 | RUBBER, MOUNT 1 | ₹ 212 | 4 | ||
| 26 | 2MSE13111000 | CYLINDER 1 | ₹ 4162 | 1 | ||
| 27 | B1XE13510000 | GASKET, CYLINDER | ₹ 440 | 1 | ||
| 28 | 5NL125640000 | PIPE WATER | ₹ 142 | 1 | ||
| 29 | 932101677200 | O RING | ₹ 60 | 1 | ||
| 30 | 995301401600 | PIN DOWEL | ₹ 5 | 2 | ||
| 31 | 1WDE48401000 | AIR CUT VALVE ASS'Y | ₹ 2835 | 1 | ||
| 32 | 1WDE48810000 | HOSE BEND 1 | ₹ 31 | 1 | ||
| 33 | 904671680100 | CLIP | ₹ 40 | 2 | ||
| 34 | 1WDE48820200 | HOSE, BEND 2 | ₹ 300 | 1 | ||
| 35 | 904671680100 | CLIP | ₹ 40 | 1 | ||
| 36 | 904671680500 | CLIP | ₹ 5 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - No description available
