FRONT WHEEL
D782
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | BS7F516810P0 | CAST WHEEL, FRONT | ₹ 22862 | 1 | DPBM15 FOR DPBMC | |
| 1B | BS7F51681098 | CAST WHEEL, FRONT | ₹ 25050 | 1 | LGB FOR SM12 | |
| 2 | 1WDF510C0100 | COLLAR ASSY. | ₹ 301 | 1 | ||
| 3 | 931062681500 | OIL SEAL | ₹ 32 | 2 | ||
| 4 | 93306302X400 | BEARING | ₹ 750 | 2 | ||
| 5 | 941111781200 | 0 | ₹ 0 | 1 | DUNLOP | |
| 6 | 939000082800 | VALVE RIM (TR412) | ₹ 200 | 1 | ||
| 7A | 5MT253980000 | BALANCER WHEEL | ₹ 138 | 1 | UN | |
| 7B | 5MT253981000 | BALANCER WHEEL(10G) | ₹ 147 | 1 | UN | |
| 7C | 5MT253982000 | BALANCER WHEEL(30G) | ₹ 156 | 1 | UN | |
| 8 | 2DPF517G0000 | ROTOR SENSOR | ₹ 296 | 1 | ||
| 9 | 901490503000 | SCREW | ₹ 21 | 3 | ||
| 10 | B5LF514A0000 | RING, WHEEL 1 (LEFT) | ₹ 885 | 1 | ||
| 11 | 1PAF53860000 | COLLAR SPROCKET AXLE | ₹ 76 | 2 | ||
| 12 | 1WD251810000 | AXLE WHEEL | ₹ 1069 | 1 | ||
| 13 | 956021420000 | NUT U FLANGE | ₹ 32 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - No description available
