DD41
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 950220601000 | BOLT FLANGE | ₹ 15 | 2 | ||
| 2 | BXUH59300900 | HYDRAULIC UNIT ASSY | ₹ 15520 | 1 | ||
| 3 | B9EH59910000 | BRACKET UNIT | ₹ 61 | 1 | ||
| 4 | 904801422900 | GROMMET | ₹ 9 | 4 | ||
| 5 | 90387068N800 | COLLAR | ₹ 13 | 4 | ||
| 6 | 950220602000 | BOLT FLANGE | ₹ 15 | 4 | ||
| 7 | BKJH59700100 | WHEEL SENSOR ASSY, FRONT | ₹ 1300 | 1 | ||
| 8 | 950270601600 | BOLT FLANGE | ₹ 5 | 1 | ||
| 9 | BCWF33180000 | HOLDER CABLE 1 | ₹ 34 | 1 | ||
| 10 | 904641201300 | CLAMP | ₹ 120 | 1 | ||
| 11 | 904641401000 | CLAMP | ₹ 70 | 1 | ||
| 12 | BGMH59800100 | WHEEL SENSOR ASSY, REAR | ₹ 760 | 1 | ||
| 13 | 950220601600 | BOLT FLANGE | ₹ 11 | 1 | ||
| 14 | 904641201300 | CLAMP | ₹ 120 | 1 | ||
| 15 | 904641401000 | CLAMP | ₹ 70 | 2 | ||
| 16 | 904641080000 | CLAMP | ₹ 127 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - This assembly focuses on the advanced safety and braking electronics of the YAMAHA XSR. It contains the high-precision Hydraulic Unit and Bracket Unit, which are central to the bike's ABS functionality. Additionally, it includes the Front and Rear Wheel Sensor Assemblies that monitor wheel speed to prevent locking during hard braking. Essential mounting hardware like grommets, collars, and cable holders are included to ensure secure routing of sensitive electronic wiring.
