DD41
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | B9EF51680133 | CAST WHEEL FRONT | ₹ 5019 | 1 | FOR WMC,VRC1,BMC | |
| 1B | B9EF516801P6 | CAST WHEEL, FRONT | ₹ 5213 | 1 | FOR NGM3 | |
| 2 | 21CF510C1000 | COLLAR ASSY. | ₹ 27 | 1 | ||
| 3 | 931062280800 | OIL SEAL | ₹ 9 | 2 | ||
| 4 | 93306202XT00 | BEARING ( USE IN REAR WHEEL H | ₹ 185 | 2 | ||
| 5 | 941101781800 | TIRE FRONT ( 100/80-17 ) MRF | ₹ 1751 | 1 | ||
| 6 | 939000082400 | VALVE RIM | ₹ 19 | 1 | ||
| 7 | B9EF517G0000 | ROTOR SENSOR | ₹ 107 | 1 | ||
| 8 | 901490503000 | SCREW | ₹ 21 | 3 | ||
| 9 | 1CKF51860000 | COLLAR WHEEL | ₹ 23 | 2 | ||
| 10 | 21CF51810000 | AXLE WHEEL | ₹ 152 | 1 | ||
| 11 | 956021420000 | NUT U FLANGE | ₹ 32 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The Front Wheel assembly focuses on the bike's steering and balance. It features the Front Cast Wheel, specialized wheel bearings, and oil seals. It also includes the Axle Wheel and the Rotor Sensor, which communicates with the ABS. This assembly is designed to provide lightweight, agile handling while maintaining the strength required for various road surfaces.
