DD41
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | DD4XF41G00P0 | COVER, TANK | ₹ 1380 | 1 | FOR WMC,BMC | |
| 1B | DD4XF41G00P4 | COVER, TANK | ₹ 1320 | 1 | FOR VRC1 | |
| 1C | DD4XF41G00P2 | COVER, TANK | ₹ 1380 | 1 | FOR NGM3 | |
| 2 | B97F15680000 | LABEL WARNING | ₹ 9 | 1 | ||
| 3 | BGPF817K0000 | LABEL FUEL | ₹ 10 | 1 | ||
| 4 | DD4F416B0000 | EMBLEM | ₹ 275 | 1 | ||
| 5 | 901090620200 | BOLT | ₹ 13 | 2 | ||
| 6 | 977025001200 | SCREW TAPPING | ₹ 11 | 2 | ||
| 7 | 902690681600 | RIVET | ₹ 12 | 2 | ||
| 8A | DD4XF41200P0 | TANK SIDE COVER 1 | ₹ 2000 | 1 | FOR WMC | |
| 8B | DD4XF41200P6 | TANK SIDE COVER 1 | ₹ 2000 | 1 | FOR VRC1 | |
| 8C | DD4XF41200P5 | TANK SIDE COVER 1 | ₹ 2000 | 1 | FOR BMC | |
| 8D | DD4XF41200P7 | TANK SIDE COVER 1 | ₹ 2000 | 1 | FOR NGM3 | |
| 9 | DD4F417B0000 | EMBLEM | ₹ 400 | 1 | FOR WMC | |
| 10A | DD4F42441000 | GRAPHIC, FUEL TANK 1 | ₹ 125 | 1 | FOR VRC1 | |
| 10B | DD4F42442000 | GRAPHIC, FUEL TANK 1 | ₹ 125 | 1 | FOR BMC | |
| 10C | DD4F42440000 | GRAPHIC, FUEL TANK 1 | ₹ 125 | 1 | FOR NGM3 | |
| 11 | DD4F42460000 | GRAPHIC 3 | ₹ 175 | 1 | FOR NGM3 | |
| 12 | 992310010000 | EMBLEM, YAMAHA | ₹ 50 | 1 | FOR NGM3 | |
| 13 | 904801280800 | GROMMET | ₹ 10 | 2 | ||
| 14 | 901190609600 | BOLT, WITH WASHER | ₹ 21 | 2 | ||
| 15 | 903870689900 | COLLAR | ₹ 30 | 2 | ||
| 16 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 17A | DD4XF41300P0 | TANK SIDE COVER 2 | ₹ 2000 | 1 | FOR WMC | |
| 17B | DD4XF41300P6 | TANK SIDE COVER 2 | ₹ 2000 | 1 | FOR VRC1 | |
| 17C | DD4XF41300P5 | TANK SIDE COVER 2 | ₹ 2000 | 1 | FOR BMC | |
| 17D | DD4XF41300P7 | TANK SIDE COVER 2 | ₹ 2000 | 1 | FOR NGM3 | |
| 18 | DD4F417B0000 | EMBLEM | ₹ 400 | 1 | FOR WMC | |
| 19A | DD4F42451000 | GRAPHIC, FUEL TANK 2 | ₹ 125 | 1 | FOR VRC1 | |
| 19B | DD4F42452000 | GRAPHIC, FUEL TANK 2 | ₹ 125 | 1 | FOR BMC | |
| 19C | DD4F42450000 | GRAPHIC, FUEL TANK 2 | ₹ 125 | 1 | FOR NGM3 | |
| 20 | DD4F42470000 | GRAPHIC | ₹ 175 | 1 | FOR NGM3 | |
| 21 | 992310010000 | EMBLEM, YAMAHA | ₹ 50 | 1 | FOR NGM3 | |
| 22 | 904801280800 | GROMMET | ₹ 10 | 2 | ||
| 23 | 901190609600 | BOLT, WITH WASHER | ₹ 21 | 2 | ||
| 24 | 903870689900 | COLLAR | ₹ 30 | 2 | ||
| 25 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 26 | DD4F137W0000 | SCOOP, AIR 1 | ₹ 140 | 1 | ||
| 27 | 901110685600 | BOLT,HEX. SOCKET BUTTON | ₹ 8 | 3 | ||
| 28 | DD4F137X0000 | SCOOP, AIR 2 | ₹ 140 | 1 | ||
| 29 | 901110685600 | BOLT,HEX. SOCKET BUTTON | ₹ 8 | 3 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - This assembly consists of the aesthetic and protective outer layers of the fuel system. It includes the decorative Tank Covers, Side Covers and Air Scoops that give the XSR its iconic look. The set is complete with the necessary emblems, graphics, and vibration-dampening grommets, allowing you to maintain or restore the bike's premium appearance.
