DD41
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BK7H14500200 | ROTOR ASSY | ₹ 1806 | 1 | ||
| 2 | BK7H14100100 | STATOR ASSY | ₹ 1419 | 1 | ||
| 3 | 913120602500 | BOLT | ₹ 7 | 3 | ||
| 4 | 913170601600 | BOLT HEX.SOCKET HD | ₹ 9 | 2 | ||
| 5 | 957071250000 | NUT FLANGE | ₹ 9 | 1 | ||
| 6 | 902011283600 | WASHER PLATE | ₹ 40 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The Generator assembly is the power plant of the motorcycle's electrical system. It consists of the Rotor Assy and Stator Assy, which work in tandem to charge the battery and power the lights and sensors while the engine is running. The assembly includes high-strength bolts and washers required to mount these heavy rotating parts securely to the crankshaft end.
