DD41
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | DD4F842M0000 | COVER 1 | ₹ 60 | 2 | ||
| 2 | 901110686300 | BOLT,HEX. SOCKET BUTTON | ₹ 7 | 4 | ||
| 3 | DD4F83650000 | COVER | ₹ 375 | 1 | ||
| 4 | 901110686800 | BOLT HEX. SOCKET BUTTON | ₹ 26 | 4 | ||
| 5 | 903870689900 | COLLAR | ₹ 30 | 4 | ||
| 6 | 904801280800 | GROMMET | ₹ 10 | 4 | ||
| 7 | 90183050A700 | NUT SPRING | ₹ 22 | 6 | ||
| 8 | DD4F83850000 | COVER, LOWER | ₹ 165 | 1 | ||
| 9 | 901110500300 | BOLT HEX. SOCKET BUTTON | ₹ 30 | 3 | ||
| 10 | DD4F83950000 | COVER, UNDER | ₹ 165 | 1 | ||
| 11 | 901110500300 | BOLT HEX. SOCKET BUTTON | ₹ 30 | 3 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - This assembly consists of the protective bodywork located around the lower engine and frame area. It includes various Lower and Under Covers that protect the engine from road debris and enhance the bike's aerodynamics. These plastic components are held in place by specialized collars, grommets, and spring nuts, ensuring they remain rattle-free even at high speeds.
