DD41
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | DD4F47301000 | DOUBLE SEAT ASSY | ₹ 2200 | 1 | ||
| 2 | 1PMF47410000 | PAD SEAT | ₹ 26 | 4 | ||
| 3 | 4LSF47410000 | PAD SEAT | ₹ 8 | 4 | ||
| 4 | 20PH21310000 | BAND BATTERY | ₹ 24 | 1 | ||
| 5 | 20PF47800000 | SEAT LOCK ASSY | ₹ 71 | 1 | ||
| 6 | 957070650000 | NUT FLANGE | ₹ 5 | 2 | ||
| 7 | DD4F478E0000 | CABLE, SEAT LOCK | ₹ 115 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - This assembly is designed for rider and pillion comfort. It features the Double Seat Assy, which is ergonomically padded and shaped to match the XSR's retro-modern style. For security and convenience, the assembly includes the Seat Lock Assy, the connecting cable, and the battery band located beneath the seat, ensuring the seating area is both comfortable and functional.
