DD41
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2FBF38730000 | BEARING, STEERING UPPER | ₹ 0 | 1 | ||
| 2 | BK7F34110000 | RACE, BALL 1 | ₹ 0 | 1 | ||
| 3 | 21CF34120000 | RACE, BALL 2 | ₹ 0 | 1 | ||
| 4 | 4LSF341E1000 | RETAINER, BALL BEARING | ₹ 0 | 1 | ||
| 5 | 20PF34160000 | COVER BALL RACE 2 | ₹ 41 | 1 | ||
| 6 | 901792561500 | NUT | ₹ 40 | 2 | ||
| 7 | 902022614200 | WASHER PLATE | ₹ 5 | 1 | ||
| 8 | 20PF34180000 | WASHER SPECIAL | ₹ 11 | 1 | ||
| 9 | BKJF34350000 | CROWN HANDLE | ₹ 945 | 1 | ||
| 10 | 913170803500 | BOLT | ₹ 14 | 2 | ||
| 11 | 901011083200 | BOLT | ₹ 90 | 1 | ||
| 12 | 902091081200 | WASHER | ₹ 43 | 1 | ||
| 13 | B9DF34410000 | HOLDER HANDLE UPPER | ₹ 194 | 1 | ||
| 14 | B9DF34420000 | HOLDER HANDLE LOWER | ₹ 207 | 2 | ||
| 15 | 901851081500 | NUT SELF-LOCKING | ₹ 24 | 2 | ||
| 16 | 913170803000 | BOLT SOCKET | ₹ 29 | 4 | ||
| 17 | 950220802000 | BOLT FLANGE | ₹ 18 | 1 | ||
| 18 | DD4F31740000 | STAY, HEADLIGHT | ₹ 1100 | 1 | ||
| 19 | B9DF317J0000 | DAMPER 1 | ₹ 10 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The Steering assembly includes the structural components that connect the handlebars to the front suspension. It features the Crown Handle (top triple tree), the specialized steering ball race covers, and the Upper and Lower Handle Holders. These parts are designed to provide a rigid and precise steering feel, ensuring the rider has total control over the motorcycle's direction.
