TRANSMISSION
0
DG53
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B7JE74100000 | MAIN AXLE COMP. | ₹ 1121 | 1 | ||
| 2 | 93306302YV00 | BEARING | ₹ 180 | 1 | ||
| 3 | 93306351Y600 | BEARING | ₹ 94 | 1 | ||
| 4 | B7JE74210000 | AXLE DRIVE | ₹ 719 | 1 | ||
| 5 | B7JE72110000 | GEAR 1ST WHEEL | ₹ 625 | 1 | ||
| 6 | 93306272YB00 | BEARING | ₹ 264 | 1 | ||
| 7 | 931023080400 | OIL SEAL | ₹ 46 | 1 | ||
| 8 | 990092540000 | CIRCLIP | ₹ 11 | 1 | ||
| 9 | 93306303YY00 | BEARING | ₹ 237 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA DG53 FASCINO 125 Series TRANSMISSION
