WINDSHIELD
DM41
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BCWF83810000 | WINDSHIELD | ₹ 398 | 1 | ||
| 2 | 901790580400 | NUT | ₹ 10 | 6 | ||
| 3 | BCWWF83500P3 | BODY COWNLING ASSY | ₹ 1278 | 1 | FOR WMC | |
| 4 | BCWF83910000 | GRAPHIC 1 | ₹ 93 | 1 | ||
| 5 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 6 | 901500502400 | SCREW ROUND HEAD | ₹ 59 | 6 | ||
| 7 | BCWF835G0000 | BODY FRONT UPPER 1 | ₹ 341 | 1 | ||
| 8 | 904801339800 | GROMMET | ₹ 10 | 1 | ||
| 9 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 10 | 977025001600 | SCREW TAPPING | ₹ 10 | 4 | ||
| 11 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 12 | 905200583800 | DAMPER PLATE | ₹ 8 | 2 | ||
| 13 | BCWF83560000 | STAY 1 | ₹ 1069 | 1 | ||
| 14 | 901050800200 | BOLT WASHER BASED | ₹ 8 | 2 | ||
| 15 | 904801356700 | GROMMET | ₹ 8 | 1 | ||
| 16 | BK7F62800000 | REAR VIEW MIRROR ASSY (LEFT) | ₹ 455 | 1 | ||
| 17 | BK7F62900000 | REAR VIEW MIRROR ASSY (RIGHT) | ₹ 455 | 1 | ||
| 18 | BCWF84830000 | PLATE RUBBER 1 | ₹ 28 | 2 | ||
| 19 | BCWF84840000 | PLATE RUBBER 2 | ₹ 180 | 1 | ||
| 20 | 913170603000 | BOLT | ₹ 15 | 4 | ||
| 21 | 903870613100 | COLLAR | ₹ 11 | 4 | ||
| 22 | BK7F16850000 | BRACKET LICENSE | ₹ 102 | 1 | ||
| 23 | 20PF34690000 | CAP BOLT | ₹ 2 | 4 | ||
| 24 | BCWF117V00P3 | COVER 7 | ₹ 1066 | 1 | FOR WMC | |
| 25 | 901830681800 | NUT SPRING | ₹ 23 | 1 | ||
| 26 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 27 | 904800155900 | GROMMET | ₹ 10 | 4 | ||
| 28 | 904801280500 | GROMMET | ₹ 8 | 1 | ||
| 29 | 903870689900 | COLLAR | ₹ 30 | 1 | ||
| 30 | 901490682900 | SCREW | ₹ 25 | 1 | ||
| 31 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 32 | BCWF172G0000 | PANEL 3 | ₹ 280 | 1 | ||
| 33 | 977025001600 | SCREW TAPPING | ₹ 10 | 4 | ||
| 34 | 904801356700 | GROMMET | ₹ 8 | 1 | ||
| 35 | 902690681300 | RIVET | ₹ 8 | 1 | ||
| 36 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 37 | 904801339800 | GROMMET | ₹ 10 | 1 | ||
| 38 | 903380718000 | PLUG | ₹ 84 | 1 | ||
| 39 | BCWF117W00P3 | COVER 8 | ₹ 1066 | 1 | FOR WMC | |
| 40 | 901830681800 | NUT SPRING | ₹ 23 | 1 | ||
| 41 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 42 | 904800155900 | GROMMET | ₹ 10 | 4 | ||
| 43 | 904801280500 | GROMMET | ₹ 8 | 1 | ||
| 44 | 903870689900 | COLLAR | ₹ 30 | 1 | ||
| 45 | 901490682900 | SCREW | ₹ 25 | 1 | ||
| 46 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 47 | BCWF172H0000 | PANEL 4 | ₹ 280 | 1 | ||
| 48 | 977025001600 | SCREW TAPPING | ₹ 10 | 4 | ||
| 49 | 904801356700 | GROMMET | ₹ 8 | 1 | ||
| 50 | 902690681300 | RIVET | ₹ 8 | 1 | ||
| 51 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 52 | 904801339800 | GROMMET | ₹ 10 | 1 | ||
| 53 | 903380718000 | PLUG | ₹ 84 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
