FENDER
DM43
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BNHXF15100P4 | FR.FENDER SUB ASSY | ₹ 1530 | 1 | FOR WMC | |
| 2 | 5TMF47862000 | EMBLEM - FAIRY SILVER | ₹ 28 | 1 | ||
| 3 | 90387068C800 | COLLAR | ₹ 16 | 6 | ||
| 4 | 904801280500 | GROMMET | ₹ 8 | 6 | ||
| 5 | 901110613700 | BOLT HEX. SOCKET BUTTON | ₹ 35 | 5 | ||
| 6 | BCWF16110000 | FENDER REAR | ₹ 170 | 1 | ||
| 7 | 901590681700 | SCREW, WITH WASHER | ₹ 10 | 2 | ||
| 8 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 9 | BK7F16290100 | GUARD MUD | ₹ 161 | 1 | ||
| 10 | BK7F834E0000 | DAMPER 1 | ₹ 14 | 2 | ||
| 11 | 90183050A700 | NUT SPRING | ₹ 22 | 4 | ||
| 12 | BK7F16170000 | BRACKET FENDER | ₹ 285 | 1 | ||
| 13 | 90387066J900 | COLLAR | ₹ 7 | 4 | ||
| 14 | BK7F16130000 | STAY FENDER 1 | ₹ 50 | 2 | ||
| 15 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 16 | 901190502200 | BOLT WITH WASHER | ₹ 3 | 4 | ||
| 17 | 901850680100 | NUT SELF-LOCKING | ₹ 5 | 4 | ||
| 18 | BCWF16420000 | GUARD FLAP | ₹ 47 | 1 | ||
| 19 | BGNF162R0000 | FENDER 2 | ₹ 295 | 1 | ||
| 20 | 901830403900 | NUT SPRING | ₹ 110 | 2 | ||
| 21 | 901730680600 | NUT, SQUARE | ₹ 11 | 1 | ||
| 22 | 901090622000 | BOLT | ₹ 19 | 2 | ||
| 23 | 902690681300 | RIVET | ₹ 8 | 1 | ||
| 24 | BK7F16410000 | BRACKET REFLECTOR | ₹ 35 | 1 | ||
| 25 | 902674884500 | RIVET BLIND | ₹ 9 | 1 | ||
| 26 | 2FCH51110000 | REFLECTOR FRONT 1 | ₹ 23 | 2 | ||
| 27 | 957070550000 | NUT FLANGE | ₹ 1 | 2 | ||
| 28 | 36LF81511100 | GRIP DRIVER | ₹ 9 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Secure at IndiaSpare. Safeguarding the internal mechanics plus ensuring a clean ride involves the specialized components found within our Front plus Rear Fender catalog for the Yamaha R15M. This section contains the primary Front Fender Sub Assy along with the specialized Mud Guard units plus original Rear Fender kits for your motorcycle. Every kit includes original Brackets alongside specialized Stay Fenders plus original Grommets plus Collar kits for professional mounting. Including various Bolt plus Rivet setups plus Nut Flange kits provided in this assembly we ensure that the plastic shields stay quiet during high velocity journeys across India. Authentic fenders protect the radiator plus electrical connectors from being damaged by flying stones or excessive rain water spray during the harsh Indian monsoon. Owners of the Yamaha R15M choose original factory bodywork for the correct texture plus color match that preserves premium aesthetics for years. Replace your broken plastics now. Grab at IndiaSpare.
