FRAME
DM43
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BCWF11100000 | FRAME COMP. | ₹ 16024 | 1 | ||
| 2 | BCWF19460000 | BRACKET SEAT FITTING | ₹ 167 | 1 | ||
| 3 | 904801356700 | GROMMET | ₹ 8 | 2 | ||
| 4 | 90387068C500 | COLLAR | ₹ 8 | 2 | ||
| 5 | 901190609600 | BOLT, WITH WASHER | ₹ 21 | 2 | ||
| 6 | 90105108A400 | BOLT FLANGE | ₹ 13 | 2 | ||
| 7 | 901051088600 | BOLT FLANGE | ₹ 119 | 2 | ||
| 8 | 901791081900 | NUT | ₹ 6 | 2 | ||
| 9 | B0TF23270000 | MUD GUARD 1 | ₹ 35 | 1 | ||
| 10 | BCWF13210000 | STAY SIDE COVER 1 | ₹ 26 | 2 | ||
| 11 | 950270601000 | BOLT FLANGE | ₹ 2 | 2 | ||
| 12 | BK7F113B0000 | DAMPER | ₹ 3 | 1 | ||
| 13 | 4LSF47410000 | PAD SEAT | ₹ 8 | 2 | ||
| 14 | 1CKF81860000 | POUCH | ₹ 36 | 1 | ||
| 15 | B0TF815P0000 | LABEL NOTICE 1 | ₹ 17 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Grab at IndiaSpare. High strength architectural engineering meets track ready performance within the Frame catalog assembly provided for every lucky plus passionate pilot of the Yamaha R15M. This specific group features the primary Frame Comp plus essential mounting hardware including Seat Brackets plus various Gasket units alongside high quality Mounting Bolts. Within this comprehensive hardware section including specialized Collar kits plus Flange Nuts plus various Damper Pads we offer everything for total structural restoration. Authentic Yamaha R15M frames undergo advanced stress testing to provide the rigidity needed for precise handling while remaining lightweight enough for high speed urban maneuvers across India. Original frame accessories like specialized Mud Guards plus Side stays ensure every fairing attaches perfectly to main structure without leaving unwanted gaps or loose sections. Source official structural spares through our storefront to maintain collision safety plus sharp chassis dynamics today. Select at IndiaSpare.
