SIDE COVER
DM43
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BCWF17110000 | COVER SIDE 1 | ₹ 129 | 1 | ||
| 2 | 904801280500 | GROMMET | ₹ 8 | 1 | ||
| 3 | 904800155900 | GROMMET | ₹ 10 | 1 | ||
| 4 | 901600581200 | SCREW ROUND TAPPING | ₹ 10 | 2 | ||
| 5 | 903870689900 | COLLAR | ₹ 30 | 1 | ||
| 6 | 901490682900 | SCREW | ₹ 25 | 1 | ||
| 7 | BCWF17210000 | COVER SIDE 2 | ₹ 128 | 1 | ||
| 8 | 904801280500 | GROMMET | ₹ 8 | 1 | ||
| 9 | 904800155900 | GROMMET | ₹ 10 | 1 | ||
| 10 | 901600581200 | SCREW ROUND TAPPING | ₹ 10 | 2 | ||
| 11 | 903870689900 | COLLAR | ₹ 30 | 1 | ||
| 12 | 901490682900 | SCREW | ₹ 25 | 1 | ||
| 13 | DM4XF17301P2 | COVER, SIDE 3 | ₹ 1560 | 1 | FOR WMC | |
| 14 | DM4F173E0000 | GRAPHIC 1 | ₹ 100 | 1 | ||
| 15 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 16 | 903871086600 | COLLAR | ₹ 41 | 1 | ||
| 17 | 901100621500 | BOLT HEXAGON SOCKET HEAD | ₹ 19 | 1 | ||
| 18 | 90109068C600 | BOLT | ₹ 18 | 2 | ||
| 19 | 901110501600 | BOLT,HEX. SOCKET BUTTON | ₹ 12 | 1 | ||
| 20 | DM4XF17401P2 | COVER, SIDE 4 | ₹ 1560 | 1 | FOR WMC | |
| 21 | DM4F173F0000 | GRAPHIC 2 | ₹ 100 | 1 | ||
| 22 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 23 | 903871086600 | COLLAR | ₹ 41 | 1 | ||
| 24 | 901100621500 | BOLT HEXAGON SOCKET HEAD | ₹ 19 | 1 | ||
| 25 | 90109068C600 | BOLT | ₹ 18 | 2 | ||
| 26 | 901110501600 | BOLT,HEX. SOCKET BUTTON | ₹ 12 | 1 | ||
| 27 | BCWF171E0000 | COVER SIDE 5 | ₹ 42 | 1 | ||
| 28 | 90183050A600 | NUT SPRING | ₹ 73 | 2 | ||
| 29 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 30 | BCWF171X0000 | COVER SIDE 6 | ₹ 63 | 1 | ||
| 31 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 2 | ||
| 32 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 33 | BCWF175N0000 | COVER FLANGE | ₹ 27 | 1 | ||
| 34 | BK7F18710000 | TANK RECOVERY | ₹ 105 | 1 | ||
| 35 | BK7F18750000 | CAP | ₹ 12 | 1 | ||
| 36 | BK7F18170000 | PIPE 2 | ₹ 81 | 1 | ||
| 37 | BK7F247A0000 | HOSE 1 | ₹ 11 | 1 | ||
| 38 | 904670800300 | CLIP OIL PIPE | ₹ 8 | 3 | ||
| 39 | 90109068B200 | BOLT | ₹ 13 | 2 | ||
| 40 | BCWF82830000 | BRACKET POUCH | ₹ 244 | 1 | ||
| 41 | BGNF82840000 | BRACKET, UNDER | ₹ 175 | 1 |
