STEERING
DM43
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2FBF38730000 | BEARING, STEERING UPPER | ₹ 0 | 1 | ||
| 2 | BK7F34110000 | RACE, BALL 1 | ₹ 0 | 1 | ||
| 3 | 21CF34120000 | RACE, BALL 2 | ₹ 0 | 1 | ||
| 4 | 4LSF341E1000 | RETAINER, BALL BEARING | ₹ 0 | 1 | ||
| 5 | 20PF34160000 | COVER BALL RACE 2 | ₹ 41 | 1 | ||
| 6 | 901792561500 | NUT | ₹ 40 | 2 | ||
| 7 | 902022614200 | WASHER PLATE | ₹ 5 | 1 | ||
| 8 | 20PF34180000 | WASHER SPECIAL | ₹ 11 | 1 | ||
| 9 | BCWF34350000 | CROWN HANDLE | ₹ 832 | 1 | ||
| 10 | 913170803000 | BOLT SOCKET | ₹ 29 | 2 | ||
| 11 | 901011083200 | BOLT | ₹ 90 | 1 | ||
| 12 | 902091081200 | WASHER | ₹ 43 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
