WATER PUMP
DM43
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BK7E24220000 | COVER HOUSING | ₹ 121 | 1 | ||
| 2 | 931031080100 | OIL SEAL | ₹ 1220 | 1 | ||
| 3 | 2DPE24280000 | GASKET HOUSING COVER 2 | ₹ 106 | 1 | ||
| 4 | BK7E11850000 | COVER CYLINDER HEAD SIDE 3 | ₹ 300 | 1 | ||
| 5 | BK7E24500000 | IMPELLER SHAFT ASSY | ₹ 144 | 1 | ||
| 6 | BK7E28420000 | CIRCLIP | ₹ 22 | 1 | ||
| 7 | 93306000Y300 | BEARING | ₹ 184 | 1 | ||
| 8 | BK7E26150000 | BOLT | ₹ 45 | 4 | ||
| 9 | BK7E24350000 | GASKET | ₹ 68 | 1 | ||
| 10 | BK7E35160000 | PIN DOWEL | ₹ 64 | 2 | ||
| 11 | 932103980300 | O-RING | ₹ 46 | 1 | ||
| 12 | BK7E24430000 | STAY | ₹ 93 | 1 | ||
| 13 | 950220602500 | BOLT FLANGE | ₹ 11 | 3 | ||
| 14 | 932101980900 | O RING | ₹ 4 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Order at IndiaSpare. Sustained hydraulic circulation through the high tech cooling jacket requires the reliable mechanical action found within our authentic Water Pump catalog for the Yamaha R15M. Our catalog provides original Water Pump covers alongside specialized Impeller Shaft gear plus high durability original Bearings needed for Indian motorcycles. Included within this assembly are various primary Gaskets plus original Oil Seals plus O-Rings for providing an airtight thermal circuit for your high performance machine today. Genuine water pumps prevent internal mixing of oil plus coolant while ensuring the impeller provides high pressure flow through every cornering session on track or road. Every Yamaha R15M owner recognizes that authenticity in mechanical drive pins plus circlip kits found here prevents failure during high RPM riding characterizing the motorcycle performance across India. Replace damaged pumps plus worn seals now. Available at IndiaSpare.
