STEERING
DM45
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2FBF38730000 | BEARING, STEERING UPPER | ₹ 0 | 1 | ||
| 2 | BK7F34110000 | RACE, BALL 1 | ₹ 0 | 1 | ||
| 3 | 21CF34120000 | RACE, BALL 2 | ₹ 0 | 1 | ||
| 4 | 4LSF341E1000 | RETAINER, BALL BEARING | ₹ 0 | 1 | ||
| 5 | 20PF34160000 | COVER BALL RACE 2 | ₹ 41 | 1 | ||
| 6 | 901792561500 | NUT | ₹ 40 | 2 | ||
| 7 | 902022614200 | WASHER PLATE | ₹ 5 | 1 | ||
| 8 | 20PF34180000 | WASHER SPECIAL | ₹ 11 | 1 | ||
| 9 | BCWF34350000 | CROWN HANDLE | ₹ 832 | 1 | ||
| 10 | 913170803000 | BOLT SOCKET | ₹ 29 | 2 | ||
| 11 | 901011083200 | BOLT | ₹ 90 | 1 | ||
| 12 | 902091081200 | WASHER | ₹ 43 | 1 | ||
| 2 | BCWF31031000 | FRONT FORK ASSY (R.H) | ₹ 10997 | 1 | ||
| 3 | BCWF31201000 | INNER TUBE COMP.2 | ₹ 2971 | 1 | ||
| 4 | BCWF22220000 | SPRING SHOCK ABSORBER 2 | ₹ 27 | 1 | ||
| 5 | BCWF31410000 | SPRING FRONT FORK | ₹ 302 | 1 | ||
| 6 | BCWF319U0000 | CAP | ₹ 97 | 1 | ||
| 7 | B48F31440000 | SEAL DUST | ₹ 240 | 1 | ||
| 8 | BCWF31530000 | RING SNAP | ₹ 25 | 1 | ||
| 9 | BK6F31450000 | OIL SEAL | ₹ 313 | 1 | ||
| 10 | BCWF31490000 | WASHER SPRING UPPER | ₹ 34 | 1 | ||
| 11 | BCWF31250000 | METAL SLIDE 1 | ₹ 94 | 1 | ||
| 12 | BCWF31710000 | PISTON FRONT FORK | ₹ 120 | 1 | ||
| 13 | BCWF31260000 | TUBE OUTER | ₹ 4053 | 1 | ||
| 14 | BCWF332K0000 | BUMP, STOP | ₹ 37 | 1 | ||
| 15 | BCWF33570000 | NUT | ₹ 24 | 1 | ||
| 16 | BCWF31111000 | BOLT CAP | ₹ 361 | 1 | ||
| 17 | BCWF31880000 | O-RING | ₹ 36 | 1 | ||
| 18 | BCWF31021000 | FRONT FORK ASSY (L.H) | ₹ 12297 | 1 | ||
| 19 | BCWF31101000 | INNER TUBE COMP.1 | ₹ 2971 | 1 | ||
| 20 | B48F31440000 | SEAL DUST | ₹ 240 | 1 | ||
| 21 | BCWF31530000 | RING SNAP | ₹ 25 | 1 | ||
| 22 | BK6F31450000 | OIL SEAL | ₹ 313 | 1 | ||
| 23 | BCWF31490000 | WASHER SPRING UPPER | ₹ 34 | 1 | ||
| 24 | BCWF31250000 | METAL SLIDE 1 | ₹ 94 | 1 | ||
| 25 | BCWF31710000 | PISTON FRONT FORK | ₹ 120 | 1 | ||
| 26 | BCWF31260000 | TUBE OUTER | ₹ 4053 | 1 | ||
| 27 | BCWF31700000 | CYLINDER COMP. FRONT FORK | ₹ 2112 | 1 | ||
| 28 | 2FSF31580000 | GASKET | ₹ 15 | 1 | ||
| 29 | BCWF31810000 | BOLT HEXAGON SOCKET HEAD | ₹ 36 | 1 | ||
| 30 | BCWF31410000 | SPRING FRONT FORK | ₹ 302 | 1 | ||
| 31 | BCWF31170000 | GUIDE, SPRING | ₹ 39 | 1 | ||
| 32 | BCWF31180000 | SPACER | ₹ 85 | 1 | ||
| 33 | BCWF33570000 | NUT | ₹ 24 | 1 | ||
| 34 | BCWF31111000 | BOLT CAP | ₹ 361 | 1 | ||
| 35 | BCWF31880000 | O-RING | ₹ 36 | 1 | ||
| 36 | BCWF33400000 | UNDER BRACKET COMP. | ₹ 2544 | 1 | ||
| 37 | 5YYF34620000 | SEAL DUST STEERING | ₹ 23 | 1 | ||
| 38 | 2FBF38750000 | .BEARING, STEERING LOWER | ₹ 0 | 1 | ||
| 39 | BCWF33460000 | BOLT 1 | ₹ 55 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Controlling the direction of your power through every tight hairpin depends on the steering head health within your original Yamaha R15 V4 machine. This Steering catalog focuses on the critical pivot points including the specialized Cover Ball Race kits plus high quality original Nuts plus specialized Washers. Every part including the Crown Handle plus Socket Bolts plus original Plate units ensures the handlebar plus fork stay perfectly synchronized during every turn. Using genuine Steering kits prevents unwanted wobble or slack that can compromise safety during high speed cruising or heavy urban traffic maneuvers. Precision items like the special Washers plus Nuts found in this assembly are made of hardened steel meant to survive intense vertical loads. R15 V4 riders seek original steering hardware to preserve the agile plus light steering feel that defines the championship pedigree of the Yamaha motorcycle. Source your steering hardware through our authorized storefront plus maintain the original balance plus accuracy of your front end steering system for years across India today.
